Measure Range: -80~+20¡æ£» -60¡«+20¡æ; -60¡«+60¡æ; (Expand type: -100~+20¡æ)
Sensor Type: Polymer Capacitive Type;
Accuracy: <¡À2¡æ;
Application: Trace moisture analysis in inert, helium, hydrogen, mixed gas streams;
Approvals: ISO9001:2008;
Area Classification: General purpose
Alarms: 2 adjustable form C relay contacts non-latching;
Calibration: 2 years each time;
Compensation: Barometric pressure and temperature; optional heated sample system and
sensor housing;
Connections: 1/4'' or 1/8'' lock type tube fittings;
Controls: Menu driven calibration, alarm and system functions;
Data Acquisition: Both ¡æ & ppm unit purity display;
Display: Graphical LCD 128¡Á64MM; resolution 0.1¡æ, display pressure, real time and
date;
Enclosure: 144(H)¡Á144(W)¡Á251(D)MM;
Flow Sensitivity: 3~5L/min recommended;
Pressure: Inlet - regulate to 0.5~2 bar, Vent-atmospheric;
Power: Universal: AC110~264V AC, 50/60Hz;
Response Time: 90% of final FS reading < 10 seconds;
Sample System: Flow control and sample/bypass valves; flow indicator;
Sensor Life: more than 36 months at 25¡æ and 1 atm;
Signal Output: 4~20mA isolated;
Temp. Range: 0~50¡æ;
Warranty: 12 months analyzer; 12 months sensor.
